Packing 305m/ Wooden drum 500m/ Wooden drum |
|---|
|
||
| Description | ||
| Rated Temperature | 75oC | |
| Standard: | UL444,TIA/EIA568A,YD/T1019-2001 | |
| Conductor: | Solid Bare copper | |
| AWG | 24 | |
| Insulation: | HDPE | |
| Twisted pair | Fifty | |
| Jacket: | PVC | |
| Rip cord: | Per request | |
| Electrical Characteristic | ||
| 1.0-100.0MHz Impedance (ohms) | 100 ohm+/- 15 ohm | |
| 1.0-350.0MHz Delay Skew (ns/100m) | <=45 | |
| Pair-to-Ground Capacitance Unbalance (pF/100m) | <=330 | |
| Max. Conductor DC Resistance 20oC (ohms/km) | 93.8 | |
| Resistance Unbalance (%) | <=5 | |
| Application | ||
| 100 Base-T4 |
|
|
| 100 Bsdr-TX | ||
| 100 VG-AnyLAN | ||
| 155 Mbps ATM | ||
| 622 Mbps ATM | ||
