Packing 305m/ Pull boxor 305m/ Spool in box |
|---|
|
||
| Description | ||
| Rated Temperature | 75oC | |
| Standard: | UL444,TIA/EIA568B.2,YD/T1019-2001 | |
| Conductor: | Solid Bare copper | |
| AWG: | 24 | |
| Insulation: | HDPE | |
| Twisted pair | Four | |
| Jacket: | PVC | |
| Rip cord: | Per request | |
| Electrical Characteristic | ||
| 1.0-100.0MHz Impedance (ohms) | 100+/-15 | |
| 1.0-350.0MHz Delay Skew (ns/100m) | <=45 | |
| Pair-to-Ground Capacitance Unbalance (pF/100m) | <=330 | |
| Max. Conductor DC Resistance 20oC (ohms/km) | 93.8 | |
| Resist | <=5 | |
| Application | ||
| 100Base-T4 |
|
|
| 100Bsdr-TX | ||
| 100VG-AnyLAN | ||
| 155Mbps ATM | ||
| 622Mbps ATM | ||
